Marine winch is specifically designed for anchoring, mooring and towing purposes as well as lifting and pulling heavy loads onto the boats. According to the power source, it can be sorted into marine electric winch, hydraulic winch, diesel winch, etc. According to the functionality it performs, it can be divided into marine anchor winch,hydraulic mooring winch, electric marine winch,anchor mooring winch, diesel towing winch and capstan winch.

More kinds marine winch for your choose:

• Electric/Hydraulic/Diesel Marine anchor winch
• Electric/Hydraulic/Diesel Marine mooring winch
• Electric/Hydraulic/Diesel marine anchor mooring winch

Electric Marine anchor winch is the device placed on deck applied for anchoring operations when a ship arrives and needs to stop at a pier or port or set sail after the stop.It makes use of an integral gearbox and motor assembly, all typically located above deck with a horizontal shaft through the unit and wheels for chain and/or rope on the other side.

Features of Electric Marine Winch:

• Electric mooring winch is a reliable and safe winch equipment in marine to berth boats and ships as well as stabilize the berth. It is generally fixed on the shore.
• This marine winch can also be installed on the boat for mooring purposes.The capacity of mooring winch is in a range of 5t to 100 tons, and the working speed is generally 10m/min.
• According to the drum configurations, our electric mooring winches can be divided into single drum winch, double drum winch and three drum winch.According to the structure, the winches can be classified into left-hand type and right-hand type.

• Anchor mooring winch is a combination of anchor windlass and mooring winch. It is an ideal choice to perform both anchoring and mooring functions in various types of vessels.
• The winch can be electrically or hydraulically driven depending on the existing infrastructure, your preference and financial considerations. It can be designed for any type or size of mooring line and any chain size to suit your winching requirements.
• The anchor and mooring winch can pull up to 100 tons. We offer a variety of optional features to make sure you end up with a perfect winch system.With highly efficient, safe and reliable operation, this equipment can bring value to various ships, like barges, passenger vessels, tankers, multi purpose vessels and inland vessels.

• Hydraulic anchor windlass is also called electro-hydraulic windlass. It drives the oil pump by the electric motor, drives the motor with high pressure oil, and then drives the transmission gear through the reducer (or no reducer) to make the windlass run.
• Its structure is relatively compact and the volume is relatively small. Small. Now there has been an automatic hydraulic windlass, which is equipped with an anchor chain length sensor. When the anchor chain needs to be thrown out, the windlass will automatically stop; can automatically decelerate; the anchor will automatically stop when it enters the anchor chain drum and is properly received.
• The composition of hydraulic anchor windlass.The hydraulic windlass is mainly composed of base, bracket, anchor chain wheel, brake, chain wheel, gearbox, electric control system, hydraulic pump station, etc.

• This Diesel anchor winch machine is a single anchor chain diesel windlass, which is composed of diesel engine, marine gear box, anchor chain wheel, auxiliary drum, clutch, reducer, drum, frame, belt brake and other components.
• The diesel windlass can be Towing heavy objects horizontally or obliquely, it is mainly used for ship berthing positioning and ship moving operations.

Generally, the electric marine winch is selected for the smaller rated pulling force. When the rated pulling force is large, you can choose a hydraulic marine winch. The hydraulic marine winch starts smoothly and will not cause impact on the power supply system.Welcome to ask Nybon for more information about lifting equipment.

Of course, which one to choose depends on your actual situation.To know which type of marine winch to buy, you first need to determine the following basic information:

You can discuss the above information with our marine winch so that they can help you make the right choice.
